python
import unreal
# Constants
WALL_MESH_PATH = "/Game/Assets/Dungeon/SM_Wall_4x2"
WALL_SPACING = 800
WALL_HEIGHT = 220
def create_wall():
# Get the editor utility library
editor_util = unreal.EditorLevelLibrary
# Before creating the wall, delete all the walls
world = editor_util.get_editor_world()
actors = unreal.GameplayStatics.get_all_actors_of_class(world, unreal.StaticMeshActor.static_class())
for actor in actors:
if actor.get_actor_label().startswith("Wall"):
editor_util.destroy_actor(actor)
# Define wall segments
wall_segments = [
{"start": unreal.Vector(0, 0, WALL_HEIGHT), "end": unreal.Vector(4800, 0, WALL_HEIGHT), "rotation": 0, "label": "Wall-Up"},
{"start": unreal.Vector(0, -4800, WALL_HEIGHT), "end": unreal.Vector(4800, -4800, WALL_HEIGHT), "rotation": 0, "label": "Wall-Down"},
{"start": unreal.Vector(-900, 200, WALL_HEIGHT), "end": unreal.Vector(-900, -3800, WALL_HEIGHT), "rotation": -90, "label": "Wall-Left"},
{"start": unreal.Vector(4600, 200, WALL_HEIGHT), "end": unreal.Vector(4600, -3800, WALL_HEIGHT), "rotation": -90, "label": "Wall-Right"},
]
# Create walls
for segment in wall_segments:
create_wall_segment(editor_util, segment["start"], segment["end"], segment["rotation"], segment["label"])
# Log a message
unreal.log("Walls created")
def create_wall_segment(editor_util, start, end, rotation, label):
# Calculate the number of walls needed
distance = unreal.Vector.distance(start, end)
num_walls = int(distance / WALL_SPACING)
for i in range(num_walls + 1):
direction = unreal.Vector.subtract(end, start).normal()
location = start + direction * (i * WALL_SPACING)
spawn_wall(editor_util, location, rotation, f"{label}-{i}")
def spawn_wall(editor_util, location, rotation, label):
actor = editor_util.spawn_actor_from_class(unreal.StaticMeshActor, location)
actor.set_actor_rotation(unreal.Rotator(0, 0, rotation), False)
# Load the static mesh
static_mesh = unreal.EditorAssetLibrary.load_asset(WALL_MESH_PATH)
static_mesh = unreal.StaticMesh.cast(static_mesh)
# Set the static mesh
static_mesh_component = actor.static_mesh_component
static_mesh_component.set_static_mesh(static_mesh)
# Set the actor's label and folder
actor.set_actor_label(label)
actor.set_folder_path(unreal.Name("/Walls"))
# Select the actor
actors_to_select = unreal.Array(unreal.Actor)
actors_to_select.append(actor)
editor_util.set_selected_level_actors(actors_to_select=actors_to_select)
if __name__ == "__main__":
create_wall()
